Thiết bị đo lực căng DN1-1000 Hans-schmidt

`Liên hệ & Báo giá chi tiết:`

`Sale ANS Vietnam:`

lien.ans@ansvietnam.com

Trực tiếp Zalo: 0902937088

Danh mục: Thiết bị đo lường & Kiểm tra, Thiết bị tự động hóa Thẻ: : DN1-1000, DN1-1000 Hans-schmidt, Đại lý Hans-schmidt Vietnam, Hans-Schmidt vietnam, Tension Meters Hand-Held-Mechanical, Thiết bị đo lực căng DN1-1000, Thiết bị đo lực căng DN1-1000 Hans-schmidt

BRAND: Hans Schmidt, Hans Schmidt Vietnam, Hans-schmidt,

Mô tả

Hans-schmidt Vietnam,Thiết bị đo lực căng DN1-1000 Hans-schmidt

Thiết bị đo lực căng DN1-1000 Hans-schmidt

ANS tự hào được sinh ra và mang trong mình sứ mệnh là đáp ứng tất cả các nhu cầu cũng như giúp Quý khách hàng tối ưu hóa các giải pháp khắc phục mọi vấn đề trong ngành công nghiệp điện tử tự động một cách hiệu quả nhất.

Chuyên nghiệp về kỹ thuật, chăm sóc khách hàng và sự hỗ trợ nhiệt tình từ các nhà sản xuất, chúng tôi luôn tự tin đáp ứng mọi yêu cầu của quý khách hàng .

Với khuynh hướng tiến cùng thời đại, phương châm của ANS chúng tôi là giúp quý khách hàng tiếp cận các thiết bị kỹ thuật hiện đại với cách sử dụng rất đơn giản, an toàn và nhanh nhất.

“Hành động kịp thời – Đáp ứng nhanh chóng – Dẫn đầu tự động – Đi đầu cải tiến”

Thêm vào đó, đội ngũ vận chuyển hàng hóa trên toàn cầu – hàng hóa nhập khẩu hàng tuần, đảm bảo thời gian, tiết kiệm chi phí, đến với ANS, bạn (quý khách)sẽ nhận được sự phục vụ tốt nhất.

Xem thêm: Các thương hiệu nổi tiếng trên thế giới mà công ty chúng tôi phân phối

SẢN PHẨM

Đại lý Hans-schmidt Vietnam,Thiết bị đo lực căng DN1-1000 Hans-schmidt,DN1-1000 Hans-schmidt,Hans-schmidt Vietnam,Thiết bị đo lực căng DN1-1000 ,: DN1-1000,Tension Meters Hand-Held-Mechanical

Đại lý Hans-schmidt Vietnam,Thiết bị đo lực căng DN1-1000 Hans-schmidt

DN1-1000 – Tension Meters Hand-Held-Mechanical

Mã hàng: DN1-1000
Tên sản phẩm: thiết bị đo lực căng – loại cầm tay
Hãng sản xuất: Hans-Schmidt
Xuất xứ: Đức
Mã hàng: https://www.hans-schmidt.com/en/produkt-details/tension-meter-dn1/

Mô tả chung DN1-1000 Hans-Schmidt:

Sản phẩm thiết bị đo lực căng DN1-1000 của Hans-Schmidt là thiết bị đo lực căng cơ học dạng cầm tay, ứng dụng linh hoạt trong ngành dệt, sợi và cáp điện.

Đặc tính nổi trội DN1-1000:

Hiệu chuẩn: Theo quy trình của nhà máy SCHMIDT
Độ chính xác: ±1 % toàn thang đo hoặc ±1 vạch chia trên thang đo
Đường kính tỷ lệ: 54 mm
Phạm vi nhiệt độ: 10 – 45 ºC
Độ ẩm không khí: 85 % RH, tối đa.
Vật liệu vỏ: Nhôm đúc

Sản phẩm tương tự:

Mã hàng	Dải đo*	Độ rộng đầu đo**	Vật liệu calib tiêu chuẩn
DN1-120	20 – 120 cN	65 mm	PA: 0.12 mm Ø
DN1-200	20 – 200 cN	65 mm	PA: 0.12 mm Ø
DN1-400	20 – 400 cN	65 mm	PA: 0.20 mm Ø
DN1-1000	50 – 1000 cN	65 mm	PA: 0.30 mm Ø
DN1-2000	200 – 2000 cN	116 mm	PA: 0.50 mm Ø
DN1-3500	400 – 3500 cN	116 mm	PA: 0.80 mm Ø
DN1-5000	400 – 5000 cN	116 mm	PA: 0.80 mm Ø
DN1-8000	500 – 8000 cN	116 mm	PA: 1.00 mm Ø
DN1-10K	2 – 10 daN	116 mm	PA: 1.00 mm Ø
DN1-20K-L	5 – 20 daN	216 mm 285 mm***	PA: 1.50 mm Ø
DN1-30K-L	5 – 30 daN	265 mm 285 mm***	PA: 1.50 mm Ø
DN1-50K-L	5 – 50 daN	265 mm 285 mm***	Steel rope: 1.5 mm Ø (7x7x0.20)

*Phạm vi dải đo và chiều rộng đầu đo có sẵn theo yêu cầu (tùy chọn)

*Đơn vị đo lường tùy chọn – G hoặc KG (tùy chọn).

** Thích hợp cho 95 % ứng dụng – PA = Polyamide Monofilament

*** Sai lệch chiều rộng đầu đo với Code V1
